General
Application |
Suitable for use in Zone 1, Zone 2, Zone 21 and Zone 22 and in Gas Groups IIA, IIB and IIC |
Ingress Protection |
IP66, IP67 and IP68 (30 metres for 7 days) to IEC/EN 60529 and NEMA 4X |
Material |
Brass, NP Brass or Stainless Steel |
Operating Temperature |
-60°C to +100 °C |
Series |
Group II Cable Glands |
Certifications and Compliance
ATEX File Number |
CML 19ATEX1167X CML 19.0045X |
CSA File Number |
CSA1015065 |
Certification |
- IEC/EN 60079-0, IEC/EN 60079-1, IEC/EN 60079-7 and IEC/EN 60079-31
- UL 60079-0, UL 60079-1, UL 60079-7, ISA 60079-31, CSA 22.2 No: 60079-0, UL 2225
- CSA 22.2 No: 60079-1, CSA 22.2 No: 60079-7, CSA 22.2 No: 60079-3
|
Hazardous Rating(s) |
- Flameproof Ex db IIC Gb, Increased Safety Ex eb IIC Gb and Dust Extb IIIC Db Ex II 2GD
- Flameproof AExd IIC Gb, Increased Safety AExe IIC Gb and Dust AExtD Zone 21
- DTS01
|
CABLE GLAND SELECTION TABLE |
Size
Ref. |
Entry Thread
Size |
Cable Acceptance Details |
‘G’
Compressed
Length |
Hexagon
Dimensions |
Male |
Female |
Metric |
NPT* |
Metric |
NPT* |
Outer Sheat'B' |
Across
Flats |
Across
Corners |
Standard |
Option |
Standard |
Option |
Standard Seal |
Alternative Seal (S) |
Min. |
Max. |
Min. |
Max. |
Os |
M20² |
½" |
- |
M20 |
- |
- |
3.2 |
8.0 |
- |
- |
54.5 |
24.0 |
26.5 |
O |
M20² |
½" |
- |
M20 |
- |
- |
6.5 |
11.9 |
- |
- |
54.5 |
24.0 |
26.5 |
A |
M20 |
¾" |
½" |
M20 |
- |
- |
10.0 |
14.3 |
9.0 |
13.4 |
56.4 |
30.0 |
32.5 |
B |
M25 |
1" |
¾" |
M25 |
- |
- |
13.0 |
20.2 |
9.5 |
15.4 |
48.2 |
36.0 |
39.5 |
C |
M32 |
1¼" |
1" |
M32 |
- |
- |
19.0 |
26.5 |
15.5 |
21.2 |
61.6 |
46.0 |
50.5 |
C2 |
M40 |
1½" |
1¼" |
M40 |
- |
- |
25.0 |
32.5 |
22.0 |
28.0 |
64.6 |
55.0 |
60.6 |
D |
M50 |
2" |
1½" |
M50 |
- |
- |
31.5 |
44.4/42.3¹ |
27.5 |
34.8 |
83.2 |
65.0 |
70.8 |
E |
M63 |
2½" |
2" |
M63 |
- |
- |
42.5 |
56.3/54.3¹ |
39.0 |
46.5 |
83.2 |
80.0 |
88.0 |
F |
M75 |
3" |
2½" |
M75 |
- |
- |
54.5 |
68.2/65.3¹ |
49.5 |
58.3 |
86.4 |
95.0 |
104.0 |
'T' — All dimensions in millimetres (except * where dimensions are in inches). Metric entry threads are 1.5mm pitch as standard. ¹ Smaller value is applicable when selecting reduced NPT male entry option.
² Sizes Os and O are available with an M16 thread size. For O size with M16 thread, the maximum cable inner sheath diameter is 10.9mm
# NPT female thread sizes equivalent to those shown in the table for the male thread size are available. Hexagon dimensions as shown may alter. |
