General
| Application | Suitable for use in Zone 1, Zone 2, Zone 21 and Zone 22 |
| Ingress Protection | IP66, IP67 and IP68 (30 metres for 7 days) to IEC/EN 60529 and NEMA 4X |
| Material | Brass, NP Brass or Stainless Steel |
| Operating Temperature | -60°C to +100 °C |
| Series | Group II Cable Glands |
Certifications and Compliance
| ATEX File Number | CML 19ATEX1167XCML 19.0045X |
| CSA File Number | CSA1015065 |
| Certification | - IEC/EN 60079-0, IEC/EN 60079-1, IEC/EN 60079-7 and IEC/EN 60079-31
- UL 60079-0, UL 60079-1, UL 60079-7, , UL 2225
- CSA 22.2 No: 60079-0, CSA 22.2 No: 60079-1, CSA 22.2 No: 60079-7, CSA 22.2 No: 60079-31
- ISA 60079-31
|
| Hazardous Rating(s) | - Flameproof Exdb IIC Gb, Increased Safety Exeb IIC Gb and Dust Extb IIIC Db Ex 2 GD
- Flameproof AExd IIC Gb, Increased Safety AExe IIC Gb and Dust AExtD Zone 21
- DTS01
|
| CABLE GLAND SELECTION TABLE |
Size
Ref. |
Entry Thread
Size |
Thread
Length
‘H’ |
Cable Acceptance Details |
‘G’
Compressed
Length |
Hexagon
Dimensions |
| Outer Sheath ‘B’ |
| Metric |
NPT
* |
Standard
Seal |
Alternative
(S) Seal |
Across
Flats |
Across
Corners |
| Standard |
Option |
Min. |
Max. |
Min. |
Max. |
| Os |
M20 ‡ |
½" |
- |
15.0 |
3.2 |
8.0 |
- |
- |
40.0 |
24.0 |
26.5 |
| O |
M20 ‡ |
½" |
- |
15.0 |
6.5 |
11.9 |
- |
- |
40.0 |
24.0 |
26.5 |
| A |
M20 |
¾" |
½" |
15.0 |
10.0 |
14.3 |
9.0 |
13.5 |
40.4 |
30.0 |
32.5 |
| B |
M25 |
1" |
¾" |
15.0 |
13.0 |
20.2 |
9.5 |
15.4 |
44.3 |
36.0 |
39.5 |
| C |
M32 |
1¼" |
1" |
15.0 |
19.5 |
26.5 |
15.5 |
21.2 |
47.2 |
46.0 |
50.5 |
| C2 |
M40 |
1½" |
1¼" |
15.0 |
25.0 |
32.5 |
22.0 |
28.0 |
49.5 |
55.0 |
60.6 |
| D |
M50 |
2" |
1½" |
15.0 |
31.5 |
44.4/42.3 † |
27.5 |
34.8 |
72.5 |
65.0 |
70.8 |
| E |
M63 |
2½" |
2" |
15.0 |
42.5 |
56.3/54.3 † |
39.0 |
46.5 |
64.8 |
80.0 |
88.0 |
| F |
M75 |
3" |
2½" |
15.0 |
54.5 |
68.2/65.3 † |
49.5 |
58.3 |
68.0 |
95.0 |
104.0 |
| G |
M80 |
3½" |
- |
20.0 |
67.0 |
73.0 |
- |
- |
68.0 |
106.4 |
115.0 |
| H |
M90 |
3½" |
- |
20.0 |
67.0 |
77.6 |
- |
- |
68.0 |
115.0 |
130.0 |
| J |
M100 |
4" |
- |
20.0 |
75.0 |
91.6 |
- |
- |
68.0 |
127.0 |
142.0 |
All dimensions in millimetres (except * where dimensions are in inches).
Os - F size metric entry threads are 1.5mm pitch as standard. For G size Cable Glands and above, a 2mm pitch is supplied as standard (1.5mm pitch with 15mm length of thread can be supplied) please specify when ordering.
† Smaller value is applicable when selecting reduced NPT entry option.
‡ Sizes Os and O are available with an M16 thread size. For O size with M16 thread, the maximum cable outer sheath diameter is 10.9 mm.
|
