CON/FO/TCM
Fiber optic converter for time code signals with amplitude modulated sine wave
carriers of 1kHz with the following inputs/outputs:
- 1 x 850nm multimode FO input via ST connector
- 2 x amplitude modulated IRIG-B, IEEE1344 or AFNOR output (according to the
input signal),
impedance: 50 Ohm, via female
BNC connectors
- 1 x power in (18 ... 72VDC / 100mA) via 3pin DFK connector
Built-up in an aluminium profile case (84mm x 24mm x 71mm / width x height x
depth).
