Greyhound GMM40 Module 4xSFP,4xRJ45 Gbit
GMM40-OOOOTTTTTV9HHS999.9.99
Product description
Description
GREYHOUND1042 Gigabit Ethernet media module
Port type and quantity
8 ports FE/GE ; 2x FE/GE SFP slot ; 2x FE/GE SFP slot ; 2x FE/GE, RJ45 ; 2x FE/GE, RJ45
Network size - length of cable
Twisted pair (TP)
port 2 and 4: 0-100 m; port 6 and 8: 0-100 m;
Single mode fiber (SM) 9/125 µm
port 1 and 3: see SFP modules; port 5 and 7: see SFP modules;
Single mode fiber (LH) 9/125 µm (long haul transceiver)
port 1 and 3: see SFP modules; port 5 and 7: see SFP modules;
Multimode fiber (MM) 50/125 µm
port 1 and 3: see SFP modules; port 5 and 7: see SFP modules;
Multimode fiber (MM) 62.5/125 µm
port 1 and 3: see SFP modules; port 5 and 7: see SFP modules;
Power requirements
Operating Voltage
via switch
Power consumption
5.5 W
Power output in BTU (IT)/h
19
Ambient conditions
MTBF (Telecordia SR-332 Issue 3) @ 25°C
8 628 357 h
Operating temperature
-40-+70 °C
Note
IEC 60068-2-2 Dry Heat Test +85°C 16 Hours
Storage/transport temperature
-40-+85 °C
Relative humidity (non-condensing)
5-95 %
Mechanical construction
Weight
490 g
Mechanical stability
IEC 60068-2-6 vibration
1 mm, 2 Hz-13.2 Hz, 90 min.; 0.7 g, 13.2 Hz-100 Hz, 90 min.; 3.5 mm, 3 Hz-9 Hz, 10 cycles, 1 octave/min.; 1 g, 9 Hz-150 Hz, 10 cycles, 1 octave/min
IEC 60068-2-27 shock
15 g, 11 ms duration, 18 shocks
EMC interference immunity
EN 61000-4-2 electrostatic discharge (ESD)
8 kV contact discharge, 15 kV air discharge
EN 61000-4-3 electromagnetic field
35 V/m (80-2700 MHz); 1 kHz, 80% AM
EN 61000-4-4 fast transients (burst)
4 kV power line, 4 kV data line
EN 61000-4-5 surge voltage
power line: 2 kV (line/earth), 1 kV (line/line); data line: 1 kV; IEEE1613: power line 5kV (line/earth)
EN 61000-4-6 Conducted Immunity
3 V (10 kHz-150 kHz), 10 V (150 kHz-80 MHz)
EN 61000-4-16 mains frequency voltage
30 V, 50 Hz continous; 300 V, 50 Hz 1 s
EMC emitted immunity
EN 55032
EN 55032 Class A
Approvals
Safety of industrial control equipment
EN61131, EN60950
Substation
IEC61850, IEEE1613
Reliability
Guarantee
60 months (please refer to the terms of guarantee for detailed information)
Scope of delivery and accessories
Scope of delivery
Device, General safety instructions
