Key Features

Programs & Verify eMMC devices in 30seconds
Programs & Verify NAND FLASH devices in 35seconds
Program 8 eMMC or NAND flash devices simultaneously.
Approved programming algorithms from IC Manufacturers

Advanced and powerful software functions.

Production mode Automatically begins programming operations once chip is inserted in socket.
Project function Set configurations once and save your project requirements for future use. Project file includes data file, configurations, programming operations.
Password Set a protected project file and control production volume
Batch command Combine programming operations like program, verify, security into a single command at any sequence.
Dynamic buffer Allowing you to program each chip with a different data file. Applications including serial number, MAC address etc.
Gang expansion Connect up 12 SPX108 to meet production demands. Manage all units under one GUI as a concurrent production programmer.
JAM/STAPL Player and Direct C Compatible.
Log file and statistic table for quality control
MES and Industrial 4 Compatible Remote communication interface and run-time database available.

Electrical and Mechanical Specification

PC Interface: USB3.0
Windows™ 7/8/10
GND banana jack
Power Supply: AC Adaptor Input AC 100V- 240V; Output: 12V/1.5A
