Keithley 2380 series Programmable electronic load

Keithley Series 2380 programmable DC electronic loads can sink a wide range of voltages and currents. The 200W Model 2380-500-15 can accept up to 500V or 15A. The 250W Model 2380-120-60 can accept up to 120V or 60A. The 750W Model 2380- 500 30 can accept up to 500V or 30A. These single-output, stand-alone electronic loads are cost-effective and self-contained.

• 200W, 250W, and 750W models
• Supports up to 500V or 60A
• Constant current (CC),constant voltage (CV), constant resistance (CR), and constant power (CP) operating modes
• LED simulated load test mode
• Readback voltage and current resolution down to 0.1mV/0.01mA
• Dynamic mode with cycle rate up to 25kHz
• Voltage rise and fall time measurement
• Current monitor function
• List mode
• Battery test mode
• Built-in GPIB,USB, and RS-232 interfaces
